CMAQ5.2测试CCTM时报错segmentation fault occurred

chenjiao997 · 发表于 2021-11-18 19:31:22

本帖最后由 chenjiao997 于 2021-12-3 18:52 编辑

请大神赐教！！！

chenjiao997 · 发表于 2021-11-19 15:20:33

#!/bin/csh -f

# ====================== CCTMv5.2 Run Script ========================
# Usage: run.cctm >&! cctm_v52b.log &
#
# To report problems or request help with this script/program:
# ===================================================================

# ==================================================================
#> Runtime Environment Options
# ==================================================================

#> Choose compiler and set up CMAQ environment with correct
#> libraries using config.cmaq. Options: intel | gcc | pgi
if ( ! $?compiler ) then
setenv compiler intel
endif

#> Source the config.cmaq file to set the build environment
cd ../..
source ./config_cmaq.csh $compiler
cd CCTM/scripts

#> Set General Parameters for Configuring the Simulation
set VRSN    = v52             #> Code Version
set PROC    = serial             #> serial or mpi
set MECH    = cb6r3_ae6_aq    #> Mechanism ID
set EMIS    = 2013ef          #> Emission Inventory Details
set APPL    = SE52BENCH       #> Application Name (e.g. Gridname)

#> Define RUNID as any combination of parameters above or others. By default,
#> this information will be collected into this one string, $RUNID, for easy
#> referencing in output binaries and log files as well as in other scripts.
setenv RUNID  ${VRSN}_${compilerString}_${APPL}

#> Set the build directory (this is where the CMAQ executable
#> is located by default).
set BLD    = ${CMAQ_HOME}/CCTM/scripts/BLD_CCTM_${VRSN}_${compilerString}
set EXEC    = CCTM_${VRSN}.exe
cat $BLD/CCTM_${VRSN}.cfg; echo " "; set echo

#> Set Working, Input, and Output Directories
setenv WORKDIR ${CMAQ_HOME}/CCTM/scripts    #> Working Directory. Where the runscript is.
setenv OUTDIR  ${CMAQ_DATA}/output_CCTM_${RUNID} #> Output Directory
setenv INPDIR  ${CMAQ_DATA}/SE52BENCH/single_day/cctm_input  #> Input Directory
setenv LOGDIR  ${OUTDIR}/LOGS    #> Log Directory Location
setenv NMLpath ${BLD}          #> Location of Namelists. Common places are:
                                 #> ${WORKDIR} | ${CCTM_SRC}/MECHS/${MECH} | ${BLD}

# =====================================================================
#> CCTM Configuration Options
# =====================================================================

#> Set Start and End Days for looping
setenv NEW_START TRUE          #> Set to FALSE for model restart
set START_DATE = "2011-07-01"    #> beginning date (July 1, 2011)
set END_DATE = "2011-07-02"    #> ending date (July 14, 2011)

#> Set Timestepping Parameters
set STTIME    = 000000          #> beginning GMT time (HHMMSS)
set NSTEPS    = 140000          #> time duration (HHMMSS) for this run
set TSTEP    = 010000          #> output time step interval (HHMMSS)

#> Horizontal domain decomposition
if ( $PROC == serial ) then
setenv NPCOL_NPROW "1 1"; set NPROCS = 1 # single processor setting
else
@ NPCOL  =  4; @ NPROW =  2
@ NPROCS = $NPCOL * $NPROW
setenv NPCOL_NPROW "$NPCOL $NPROW";
endif

#> Vertical extent
set NZ       = 35

#setenv LOGFILE $CMAQ_HOME/$RUNID.log  #> log file name; uncomment to write standard output to a log, otherwise write to screen

setenv GRID_NAME SE52BENCH       #> check GRIDDESC file for GRID_NAME options
setenv GRIDDESC $INPDIR/GRIDDESC #> grid description file

#> Output Species and Layer Options
#> CONC file species; comment or set to "ALL" to write all species to CONC
#setenv CONC_SPCS "O3 NO ANO3I ANO3J NO2 FORM ISOP ANH4J ASO4I ASO4J"
#setenv CONC_BLEV_ELEV " 1 4" #> CONC file layer range; comment to write all layers to CONC

#> ACONC file species; comment or set to "ALL" to write all species to ACONC
#setenv AVG_CONC_SPCS "O3 NO CO NO2 ASO4I ASO4J NH3"
setenv AVG_CONC_SPCS "ALL"
setenv ACONC_BLEV_ELEV " 1 1" #> ACONC file layer range; comment to write all layers to ACONC
setenv AVG_FILE_ENDTIME N    #> override default beginning ACON timestamp [ default: N ]

setenv EXECUTION_ID $EXEC #> define the model execution id

#> Sychronization Time Step and Tolerance Options
setenv CTM_MAXSYNC 300    #> max sync time step (sec) [ default: 720 ]
setenv CTM_MINSYNC  60    #> min sync time step (sec) [ default: 60 ]
setenv SIGMA_SYNC_TOP 0.7 #> top sigma level thru which sync step determined [ default: 0.7 ]
#setenv ADV_HDIV_LIM 0.95    #> maximum horiz. div. limit for adv step adjust [ default: 0.9 ]
setenv CTM_ADV_CFL 0.95    #> max CFL [ default: 0.75]
#setenv RB_ATOL 1.0E-09    #> global ROS3 solver abs tol [ default: 1.0E-07 ]

#> Science Options
setenv CTM_WB_DUST Y       #> use inline windblown dust emissions [ default: Y ]
setenv CTM_ERODE_AGLAND Y #> use agricultural activity for windblown dust
                           #> [ default: N ]; ignore if CTM_WB_DUST = N
setenv CTM_WBDUST_BELD BELD3 #> landuse database for identifying dust source regions
                           #> [ default: BELD3 ]; ignore if CTM_WB_DUST = N
setenv CTM_LTNG_NO Y       #> turn on lightning NOx [ default: N ]
setenv CTM_WVEL Y          #> save derived vertical velocity component to conc
                           #> file [ default: N ]
setenv KZMIN Y             #> use Min Kz option in edyintb [ default: Y ],
                           #> otherwise revert to Kz0UT
setenv CTM_ILDEPV Y       #> calculate in-line deposition velocities [ default: Y ]
setenv CTM_MOSAIC N       #> landuse specific deposition velocities [ default: N ]
setenv CTM_FST N          #> mosaic method to get land-use specific stomatal flux
                           #> [ default: N ]
setenv CTM_ABFLUX Y       #> ammonia bi-directional flux for in-line deposition
                           #> velocities [ default: N ]; ignore if CTM_ILDEPV = N
setenv CTM_HGBIDI N       #> mercury bi-directional flux for in-line deposition
                           #> velocities [ default: N ]; ignore if CTM_ILDEPV = N
setenv CTM_SFC_HONO Y       #> surface HONO interaction [ default: Y ]; ignore if CTM_ILDEPV = N
setenv CTM_GRAV_SETL Y    #> vdiff aerosol gravitational sedimentation [ default: Y ]
setenv CTM_BIOGEMIS Y       #> calculate in-line biogenic emissions [ default: N ]
setenv CTM_PT3DEMIS Y       #> calculate in-line plume rise for elevated point emissions
                           #> [ default: N ]
setenv CTM_ZERO_PCSOA N    #> turn off the emissions of the VOC precursor to pcSOA.
                           #> The CMAQ dev team recommends leaving pcSOA mass in the
                           #> model for production runs. [ default: N ]

#> Process Analysis Options
setenv CTM_PROCAN N       #> use process analysis [ default: N]
#> process analysis global column, row and layer ranges
#> user must check GRIDDESC for validity!
setenv PA_BCOL_ECOL "10 320"
setenv PA_BROW_EROW "10 195"
setenv PA_BLEV_ELEV "1  4"

#> I/O Controls
setenv IOAPI_LOG_WRITE F    #> turn on excess WRITE3 logging [ options: T | F ]
setenv FL_ERR_STOP N       #> stop on inconsistent input files
setenv PROMPTFLAG F       #> turn on I/O-API PROMPT*FILE interactive mode [ options: T | F ]
setenv IOAPI_OFFSET_64 NO #> support large timestep records (>2GB/timestep record) [ options: YES | NO ]
setenv CTM_EMISCHK N       #> Abort CMAQ if missing surrogates from emissions Input files

#> Aerosol Diagnostic Controls
setenv CTM_AVISDIAG Y       #> Aerovis diagnostic file [ default: N ]
setenv CTM_PMDIAG Y       #> Instantaneous Aerosol Diagnostic File [ default: Y ]
setenv CTM_APMDIAG Y       #> Hourly-Average Aerosol Diagnostic File [ default: Y ]
setenv APMDIAG_BLEV_ELEV "1 3" #> layer range for average pmdiag
setenv APMDIAG_BLEV_ELEV ""  #> layer range for average pmdiag = NLAYS

#> Diagnostic Output Flags
setenv CTM_CKSUM Y          #> cksum report [ default: Y ]
setenv CLD_DIAG Y          #> cloud diagnostic file [ default: N ]
setenv CTM_AERDIAG Y       #> aerosol diagnostic file [ default: N ]
setenv CTM_PHOTDIAG Y       #> photolysis diagnostic file [ default: N ]
setenv CTM_SSEMDIAG Y       #> sea-salt emissions diagnostic file [ default: N ]
setenv CTM_DUSTEM_DIAG Y    #> windblown dust emissions diagnostic file [ default: N ]; ignore if CTM_WB_DUST = N
setenv CTM_DEPV_FILE Y    #> deposition velocities diagnostic file [ default: N ]
setenv VDIFF_DIAG_FILE Y    #> vdiff & possibly aero grav. sedimentation diagnostic file [ default: N ]
setenv LTNGDIAG Y          #> lightning diagnostic file [ default: N ]
setenv CTM_AOD Y          #> AOD diagnostic file [ default: N ]
setenv B3GTS_DIAG Y       #> beis mass emissions diagnostic file [ default: N ]
setenv PT3DDIAG N          #> optional 3d point source emissions diagnostic file [ default: N]; ignore if CTM_PT3DEMIS = N
setenv PT3DFRAC N          #> optional layer fractions diagnostic (play) file(s) [ default: N]; ignore if CTM_PT3DEMIS = N
setenv REP_LAYER_MIN -1    #> Minimum layer for reporting plume rise info [ default: -1 ]

set DISP = delete          #> [ delete | keep ] existing output files

# =====================================================================
#> Input Directories and Filenames
# =====================================================================

set ICpath = $INPDIR/icbc             #> initial conditions input directory
set BCpath = $INPDIR/icbc             #> boundary conditions input directory
set EMISpath  = $INPDIR/emis/gridded_area #> surface emissions input directory
set IN_PTpath = $INPDIR/emis/inln_point #> elevated emissions input directory (in-line point only)
set IN_LTpath = $INPDIR/lightning       #> lightning NOx input directory
set METpath = $INPDIR/met/mcip       #> meteorology input directory
#set JVALpath  = $INPDIR/jproc          #> offline photolysis rate table directory
set OMIpath = $BLD                   #> ozone columne data for the photolysis model
set LUpath = $INPDIR/land             #> BELD landuse data for windblown dust model
set SZpath = $INPDIR/land             #> surf zone file for in-line seasalt emissions

set ICBC_CASE = 2013ef_v6_13g_s07       #> Version label for the ICBCs
set EMIS_CASE = 2013ef_v6_13g_s07_hg    #> Version Label for the Emissions

# =====================================================================
#> Begin Loop Through Simulation Days
# =====================================================================

set TODAYG = ${START_DATE}
set TODAYJ = `date -ud "${START_DATE}" +%Y%j` #> Convert YYYY-MM-DD to YYYYJJJ
set STOP_DAY = `date -ud "${END_DATE}" +%Y%j` #> Convert YYYY-MM-DD to YYYYJJJ

while ($TODAYJ <= $STOP_DAY )  #>Compare dates in terms of YYYYJJJ

  #> Retrieve Calendar day Information
  set YYYYMMDD = `date -ud "${TODAYG}" +%Y%m%d` #> Convert YYYY-MM-DD to YYYYMMDD
  set YYMMDD = `date -ud "${TODAYG}" +%y%m%d` #> Convert YYYY-MM-DD to YYMMDD
  set YYYYJJJ = $TODAYJ

  #> Calculate Yesterday's Date
  set YESTERDAY = `date -ud "${TODAYG}-1days" +%Y%m%d` #> Convert YYYY-MM-DD to YYYYJJJ

# =====================================================================
#> Input Files (Some are Day-Dependent)
# =====================================================================

  #> Initial conditions
  if ($NEW_START == true || $NEW_START == TRUE ) then
   setenv ICFILE ICON_20110630_bench.nc
   setenv INITIAL_RUN Y #related to restart soil information file
   rm -rf $LOGDIR/CTM_LOG*${RUNID}*  # Remove all Log Files Since this is a new start
   mkdir -p $OUTDIR
  else
   set ICpath = $OUTDIR
   setenv ICFILE CCTM_CGRID_${RUNID}_${YESTERDAY}.nc
   setenv INITIAL_RUN N
  endif

  #> Boundary conditions
  set BCFILE = BCON_${YYYYMMDD}_bench.nc

  #> Off-line photolysis rates
  #set JVALfile  = JTABLE_${YYYYJJJ}

  #> Ozone column data
  set OMIfile = OMI_1979_to_2015.dat

  #> Optics file
  set OPTfile = PHOT_OPTICS.dat

  #> MCIP meteorology files
  setenv GRID_BDY_2D $METpath/GRIDBDY2D_${YYMMDD}.nc
  setenv GRID_CRO_2D $METpath/GRIDCRO2D_${YYMMDD}.nc
  setenv GRID_CRO_3D $METpath/GRIDCRO3D_${YYMMDD}.nc
  setenv GRID_DOT_2D $METpath/GRIDDOT2D_${YYMMDD}.nc
  setenv MET_CRO_2D $METpath/METCRO2D_${YYMMDD}.nc
  setenv MET_CRO_3D $METpath/METCRO3D_${YYMMDD}.nc
  setenv MET_DOT_3D $METpath/METDOT3D_${YYMMDD}.nc
  setenv MET_BDY_3D $METpath/METBDY3D_${YYMMDD}.nc

  setenv LAYER_FILE $MET_CRO_3D  # Deprecated: MET_CRO_3D is now read directly in CCTM

  #> Emissions files
  if ( $CTM_PT3DEMIS == 'N' ) then
   #> Offline 3d emissions file name
   set EMISfile  = emis_mole_all_${YYYYMMDD}_cb6_bench.nc
  else
   #> In-line emissions configuration
   set STKCASEG = 12US1_2011ek_cb6cmaq_v6_11g          # Stack Group Version Label
   set STKCASEE = 12US1_cmaq_cb6e51_2011ek_cb6cmaq_v6_11g # Stack Emission Version Label
   set EMISfile  = emis_mole_all_${YYYYMMDD}_cb6_bench.nc #> Surface emissions
   setenv NPTGRPS 5       #> Number of elevated source groups

   setenv STK_GRPS_01 $IN_PTpath/stack_groups/stack_groups_ptnonipm_${STKCASEG}.nc
   setenv STK_GRPS_02 $IN_PTpath/stack_groups/stack_groups_ptegu_${STKCASEG}.nc
   setenv STK_GRPS_03 $IN_PTpath/stack_groups/stack_groups_othpt_${STKCASEG}.nc
   setenv STK_GRPS_04 $IN_PTpath/stack_groups/stack_groups_ptfire_${YYYYMMDD}_${STKCASEG}.nc
   setenv STK_GRPS_05 $IN_PTpath/stack_groups/stack_groups_pt_oilgas_${STKCASEG}.nc
   setenv LAYP_STTIME $STTIME
   setenv LAYP_NSTEPS $NSTEPS

   setenv STK_EMIS_01 $IN_PTpath/ptnonipm/inln_mole_ptnonipm_${YYYYMMDD}_${STKCASEE}.nc
   setenv STK_EMIS_02 $IN_PTpath/ptegu/inln_mole_ptegu_${YYYYMMDD}_${STKCASEE}.nc
   setenv STK_EMIS_03 $IN_PTpath/othpt/inln_mole_othpt_${YYYYMMDD}_${STKCASEE}.nc
   setenv STK_EMIS_04 $IN_PTpath/ptfire/inln_mole_ptfire_${YYYYMMDD}_${STKCASEE}.nc
   setenv STK_EMIS_05 $IN_PTpath/pt_oilgas/inln_mole_pt_oilgas_${YYYYMMDD}_${STKCASEE}.nc
   setenv LAYP_STDATE $YYYYJJJ
  endif

  #> Lightning NOx configuration
  if ( $CTM_LTNG_NO == 'Y' ) then
   setenv LTNGNO "InLine" #> set LTNGNO to "Inline" to activate in-line calculation

  #> In-line lightning NOx options
   setenv USE_NLDN  Y       #> use hourly NLDN strike file [ default: Y ]
   if ( $USE_NLDN == Y ) then
      setenv NLDN_STRIKES $INPDIR/lightning/NLDN.12US1.${YYYYMMDD}_bench.nc
   else
      setenv LOG_START 2.0 #> RC value to transit linear to log linear
   endif
   setenv LTNGPARMS_FILE $INPDIR/lightning/LTNG_AllParms_12US1_bench.nc #> lightning parameter file
  endif

  #> In-line biogenic emissions configuration
  if ( $CTM_BIOGEMIS == 'Y' ) then
   set IN_BEISpath = ${INPDIR}/land
   set GSPROpath = ${IN_BEISpath}
   setenv GSPRO    $GSPROpath/gspro_biogenics_1mar2017.txt
   setenv B3GRD    $IN_BEISpath/b3grd_bench.nc
   setenv BIOG_SPRO  B10C6 #> speciation profile to use for biogenics
   setenv BIOSW_YN Y    #> use frost date switch [ default: Y ]
   setenv BIOSEASON  $IN_BEISpath/bioseason.cmaq.2011_12US1_wetland100.ghrsst_bench.ncf #> ignore season switch file if BIOSW_YN = N
   setenv SUMMER_YN  Y    #> Use summer normalized emissions? [ default: Y ]
   setenv PX_VERSION Y    #> MCIP is PX version? [ default: N ]
   setenv SOILINP $OUTDIR/CCTM_SOILOUT_${RUNID}_${YESTERDAY}.nc
                           #> Biogenic NO soil input file; ignore if INITIAL_RUN = Y
  endif

  #> Windblown dust emissions configuration
  if ( $CTM_WB_DUST == 'Y' ) then
   # Input variables for BELD3 Landuse option
   setenv DUST_LU_1 $LUpath/beld3_12US1_459X299_output_a_bench.nc
   setenv DUST_LU_2 $LUpath/beld4_12US1_459X299_output_tot_bench.nc
   setenv MODIS_FPAR $LUpath/modis_bench.nc

   if ( $CTM_ERODE_AGLAND == 'Y' ) then
      setenv CROPMAP01 ${INPDIR}/land/BeginPlanting_12km_bench.nc
      setenv CROPMAP04 ${INPDIR}/land/EndPlanting_12km_bench.nc
      setenv CROPMAP08 ${INPDIR}/land/EndHarvesting_12km_bench.nc
   endif
  endif

  #> In-line sea salt emisisions configuration
  setenv OCEAN_1 $SZpath/12US1_surf_bench.nc #> horizontal grid-dependent surf zone file

  #> Bidiretional ammonia configuration
  if ( $CTM_ABFLUX == 'Y' ) then
   setenv E2C_Soilfile  ${INPDIR}/land/2011_US1_soil_bench.nc
   setenv E2C_Fertfile  ${INPDIR}/land/2011_US1_time${YYYYMMDD}_bench.nc
   setenv B4LU_file    ${INPDIR}/land/beld4_12kmCONUS_2006nlcd_bench.nc
   setenv E2C_SOIL ${E2C_Soilfile}
   setenv E2C_FERT ${E2C_Fertfile}
   setenv BELD4_LU ${B4LU_file}
  endif

# =====================================================================
#> Output Files
# =====================================================================
  #> set output file name extensions
  setenv CTM_APPL ${RUNID}_${YYYYMMDD}
  #> set output file names
  setenv S_CGRID       "$OUTDIR/CCTM_CGRID_${CTM_APPL}.nc"       #> 3D Inst. Concenctrations
  setenv CTM_CONC_1    "$OUTDIR/CCTM_CONC_${CTM_APPL}.nc -v"    #> On-Hour Concentrations
  setenv A_CONC_1       "$OUTDIR/CCTM_ACONC_${CTM_APPL}.nc -v"    #> Hourly Avg. Concentrations
  setenv MEDIA_CONC    "$OUTDIR/CCTM_MEDIA_CONC_${CTM_APPL}.nc -v" #> NH3 Conc. in Media
  setenv CTM_DRY_DEP_1 "$OUTDIR/CCTM_DRYDEP_${CTM_APPL}.nc -v"    #> Hourly Dry Deposition
  setenv CTM_DEPV_DIAG "$OUTDIR/CCTM_DEPV_${CTM_APPL}.nc -v"    #> Dry Deposition Velocities
  setenv CTM_PT3D_DIAG "$OUTDIR/CCTM_PT3D_${CTM_APPL}.nc -v"    #>
  setenv B3GTS_S       "$OUTDIR/CCTM_B3GTS_S_${CTM_APPL}.nc -v" #> Biogenic Emissions
  setenv SOILOUT       "$OUTDIR/CCTM_SOILOUT_${CTM_APPL}.nc"    #> Soil Emissions
  setenv CTM_WET_DEP_1 "$OUTDIR/CCTM_WETDEP1_${CTM_APPL}.nc -v" #> Wet Dep From All Clouds
  setenv CTM_WET_DEP_2 "$OUTDIR/CCTM_WETDEP2_${CTM_APPL}.nc -v" #> Wet Dep From SubGrid Clouds
  setenv CTM_VIS_1    "$OUTDIR/CCTM_PMVIS_${CTM_APPL}.nc -v"    #> On-Hour Visibility
  setenv CTM_AVIS_1    "$OUTDIR/CCTM_APMVIS_${CTM_APPL}.nc -v"    #> Hourly-Averaged Visibility
  setenv CTM_PMDIAG_1 "$OUTDIR/CCTM_PMDIAG_${CTM_APPL}.nc -v"    #> On-Hour Particle Diagnostics
  setenv CTM_APMDIAG_1 "$OUTDIR/CCTM_APMDIAG_${CTM_APPL}.nc -v" #> Hourly Avg. Particle Diagnostic
  setenv CTM_RJ_1       "$OUTDIR/CCTM_PHOTDIAG1_${CTM_APPL}.nc -v"  #> Photolysis Rxn Diagnostics
  setenv CTM_RJ_2       "$OUTDIR/CCTM_PHOTDIAG2_${CTM_APPL}.nc -v"  #> Photolysis Rates Output
  setenv CTM_SSEMIS_1 "$OUTDIR/CCTM_SSEMIS_${CTM_APPL}.nc -v"    #> Sea Spray Emissions
  setenv CTM_DUST_EMIS_1 "$OUTDIR/CCTM_DUSTEMIS_${CTM_APPL}.nc -v" #> Dust Emissions
  setenv CTM_IPR_1    "$OUTDIR/CCTM_PA_1_${CTM_APPL}.nc -v"    #> Process Analysis
  setenv CTM_IPR_2    "$OUTDIR/CCTM_PA_2_${CTM_APPL}.nc -v"    #> Process Analysis
  setenv CTM_IPR_3    "$OUTDIR/CCTM_PA_3_${CTM_APPL}.nc -v"    #> Process Analysis
  setenv CTM_IRR_1    "$OUTDIR/CCTM_IRR_1_${CTM_APPL}.nc -v"    #> Chem Process Analysis
  setenv CTM_IRR_2    "$OUTDIR/CCTM_IRR_2_${CTM_APPL}.nc -v"    #> Chem Process Analysis
  setenv CTM_IRR_3    "$OUTDIR/CCTM_IRR_3_${CTM_APPL}.nc -v"    #> Chem Process Analysis
  setenv CTM_DRY_DEP_MOS "$OUTDIR/CCTM_DDMOS_${CTM_APPL}.nc -v"    #> Dry Dep
  setenv CTM_DRY_DEP_FST "$OUTDIR/CCTM_DDFST_${CTM_APPL}.nc -v"    #> Dry Dep
  setenv CTM_DEPV_MOS "$OUTDIR/CCTM_DEPVFST_${CTM_APPL}.nc -v" #> Dry Dep Velocity
  setenv CTM_DEPV_FST "$OUTDIR/CCTM_DEPVMOS_${CTM_APPL}.nc -v" #> Dry Dep Velocity
  setenv CTM_VDIFF_DIAG  "$OUTDIR/CCTM_VDIFF_DIAG_${CTM_APPL}.nc -v" #> Vertical Dispersion Diagnostic
  setenv CTM_VSED_DIAG "$OUTDIR/CCTM_VSED_DIAG_${CTM_APPL}.nc -v"  #> Particle Grav. Settling Velocity
  setenv CTM_AOD_1    "$OUTDIR/CCTM_AOD_DIAG_${CTM_APPL}.nc -v" #> Aerosol Optical Depth Diagnostic
  setenv CTM_LTNGDIAG_1  "$OUTDIR/CCTM_LTNGHRLY_${CTM_APPL}.nc -v" #> Hourly Avg Lightning NO
  setenv CTM_LTNGDIAG_2  "$OUTDIR/CCTM_LTNGCOL_${CTM_APPL}.nc -v" #> Column Total Lightning NO

  #> set floor file (neg concs)
  setenv FLOOR_FILE ${OUTDIR}/FLOOR_${CTM_APPL}.txt

  #> create output directory
  if ( ! -d "$OUTDIR" ) mkdir -p $OUTDIR

  #> look for existing log files and output files
  set log_test = `ls CTM_LOG_???.${CTM_APPL}`
  set OUT_FILES = (${FLOOR_FILE} ${S_CGRID} ${CTM_CONC_1} ${A_CONC_1} ${MEDIA_CONC}       \
         ${CTM_DRY_DEP_1} $CTM_DEPV_DIAG $CTM_PT3D_DIAG $B3GTS_S $SOILOUT $CTM_WET_DEP_1\
         $CTM_WET_DEP_2 $CTM_VIS_1 $CTM_AVIS_1 $CTM_PMDIAG_1 $CTM_APMDIAG_1          \
         $CTM_RJ_1 $CTM_RJ_2 $CTM_SSEMIS_1 $CTM_DUST_EMIS_1 $CTM_IPR_1 $CTM_IPR_2    \
         $CTM_IPR_3 $CTM_IRR_1 $CTM_IRR_2 $CTM_IRR_3 $CTM_DRY_DEP_MOS                \
         $CTM_DRY_DEP_FST $CTM_DEPV_MOS $CTM_DEPV_FST $CTM_VDIFF_DIAG $CTM_VSED_DIAG \
         $CTM_AOD_1 $CTM_LTNGDIAG_1 $CTM_LTNGDIAG_2)
  set OUT_FILES = `echo $OUT_FILES | sed "s; -v;;g" `
  echo $OUT_FILES
  set out_test = `ls $OUT_FILES`

  #> delete previous output if requested
  if ( $DISP == 'delete' ) then
   #> remove previous log files
   echo " ancillary log files being deleted"
   foreach file ( $log_test )
      echo " deleting $file"
      /bin/rm -f $file
   end

   #> remove previous output files
   echo " output files being deleted"
   foreach file ( $out_test )
      echo " deleting $file"
      /bin/rm -f $file
   end

  else
   #> error if previous log files exist
   if ( "$log_test" != "" ) then
   echo "*** Logs exist - run ABORTED ***"
   echo "*** To overide, set $DISP == delete in run_cctm.csh ***"
   echo "*** and these files will be automatically deleted. ***"
   exit 1
   endif

   #> error if previous output files exist
   if ( "$out_test" != "" ) then
   echo "*** Output Files Exist - run will be ABORTED ***"
   foreach file ( $out_test )
      echo " cannot delete $file"
   end
   echo "*** To overide, set $DISP == delete in run_cctm.csh ***"
   echo "*** and these files will be automatically deleted. ***"
   exit 1
   endif
  endif

  #> for the run control ...
  setenv CTM_STDATE    $YYYYJJJ
  setenv CTM_STTIME    $STTIME
  setenv CTM_RUNLEN    $NSTEPS
  setenv CTM_TSTEP    $TSTEP
  setenv EMIS_1 $EMISpath/$EMISfile
  setenv INIT_GASC_1 $ICpath/$ICFILE
  setenv INIT_AERO_1 $INIT_GASC_1
  setenv INIT_NONR_1 $INIT_GASC_1
  setenv INIT_TRAC_1 $INIT_GASC_1
  setenv BNDY_GASC_1 $BCpath/$BCFILE
  setenv BNDY_AERO_1 $BNDY_GASC_1
  setenv BNDY_NONR_1 $BNDY_GASC_1
  setenv BNDY_TRAC_1 $BNDY_GASC_1
  setenv OMI $OMIpath/$OMIfile
  setenv OPTICS_DATA $OMIpath/$OPTfile
  #setenv XJ_DATA $JVALpath/$JVALfile
  set TR_DVpath = $METpath
  set TR_DVfile = $MET_CRO_2D

  #> species defn & photolysis
  setenv gc_matrix_nml ${NMLpath}/GC_$MECH.nml
  setenv ae_matrix_nml ${NMLpath}/AE_$MECH.nml
  setenv nr_matrix_nml ${NMLpath}/NR_$MECH.nml
  setenv tr_matrix_nml ${NMLpath}/Species_Table_TR_0.nml

  #> check for photolysis input data
  setenv CSQY_DATA ${NMLpath}/CSQY_DATA_$MECH

  if (! (-e $CSQY_DATA ) ) then
   echo " $CSQY_DATA  not found "
   exit 1
  endif
  if (! (-e $OPTICS_DATA ) ) then
   echo " $OPTICS_DATA  not found "
   exit 1
  endif

# ===================================================================
#> Execution Portion
# ===================================================================

  #> Print attributes of the executable
  ls -l $BLD/$EXEC; size $BLD/$EXEC
  unlimit
  #limit

  date

  #> Executable call for single PE, uncomment to invoke
  # /usr/bin/time  $BLD/$EXEC

  #> Executable call for multi PE, configure for your system
  set MPI = /home/Intel_Libs/openmpi-3.1.2/bin
  set MPIRUN = $MPI/mpirun
  #time mpirun -r ssh -np $NPROCS $BLD/$EXEC
  #time mpirun -np $NPROCS $BLD/$EXEC
  time mpirun $BLD/$EXEC

  date

# ===================================================================
#> Finalize Run for This Day and Loop to Next Day
# ===================================================================

  #> Save Log Files and Move on to Next Simulation Day
  if (! -e $LOGDIR ) then
mkdir $LOGDIR
  endif
  mv CTM_LOG_???.${CTM_APPL} $LOGDIR

  #> The next simulation day will, by definition, be a restart
  setenv NEW_START false

  #> Increment both Gregorian and Julian Days
  set TODAYG = `date -ud "${TODAYG}+1days" +%Y-%m-%d` #> Add a day for tomorrow
  set TODAYJ = `date -ud "${TODAYG}" +%Y%j` #> Convert YYYY-MM-DD to YYYYJJJ

end  #Loop to the next Simulation Day

exit

累死的绿树 · 发表于 2021-11-25 09:50:44

前面用的串行，后面是并行提交，应该有问题吧？

chenjiao997 · 发表于 2021-11-25 18:57:46

并行串行都会提示这个错误

chenjiao997 · 发表于 2021-12-3 18:53:08

&time_control
run_days                = 0,
run_hours             = 18,
run_minutes             = 0,
run_seconds             = 0,
start_year             = 2019,
start_month             = 3,
start_day             = 17,
start_hour             = 0,
start_minute          = 00,
start_second          = 00,
end_year                = 2019,
end_month             = 3,
end_day                = 17,
end_hour                = 18,
end_minute             = 00,
end_second             = 00,
interval_seconds       = 21600,
input_from_file       = .true.,
history_interval       = 180,
frames_per_outfile    = 1000,
restart                = .false.,
restart_interval       = 5000,
io_form_history       = 2,
io_form_restart       = 2,
io_form_input          = 2,
io_form_boundary       = 2,
debug_level             = 0,
/

&domains
time_step             = 180,
time_step_fract_num    = 0,
time_step_fract_den    = 1,
max_dom                = 1,
e_we                   = 66,
e_sn                   = 59,
e_vert                = 30,
p_top_requested       = 5000,
num_metgrid_levels    = 32,
num_metgrid_soil_levels  = 4,
dx                      = 11300,
dy                      = 11300,
grid_id                = 1,
parent_id             = 0,
i_parent_start          = 1,
j_parent_start          = 1,
parent_grid_ratio       = 1,
parent_time_step_ratio = 1,
feedback                = 1,
smooth_option          = 0,
/

&physics
mp_physics             = 3,
ra_lw_physics          = 1,
ra_sw_physics          = 1,
radt                   = 30,
sf_sfclay_physics       = 1,
sf_surface_physics    = 2,
bl_pbl_physics          = 1,
bldt                   = 0,
cu_physics             = 1,
cudt                   = 5,
isfflx                = 1,
ifsnow                = 1,
icloud                = 1,
surface_input_source    = 3,
num_soil_layers       = 4,
num_land_cat          = 21,
sf_urban_physics       = 0,
/

&fdda
/

&dynamics
w_damping             = 0,
diff_opt                = 1,
km_opt                = 4,
diff_6th_opt          = 0,
diff_6th_factor       = 0.12,
base_temp             = 290.,
damp_opt                = 0,
zdamp                   = 5000.,
dampcoef                = 0.2,
khdif                   = 0,
kvdif                   = 0,
non_hydrostatic       = .true.,
moist_adv_opt          = 1,
scalar_adv_opt          = 1,
/

&bdy_control
spec_bdy_width          = 5,
spec_zone             = 1,
relax_zone             = 4,
specified             = .true.,
nested                = .false.,
/

&grib2
/

&namelist_quilt
nio_tasks_per_group    = 0,
nio_groups             = 1,
/

chenjiao997 · 发表于 2021-12-3 19:02:24

&FILENAMES
  file_gd = "/home/CMAQ-5.2/data/mcip/SE52BENCH/GRIDDESC"
  file_hdr = "/home/CMAQ-5.2/data/mcip/SE52BENCH/mmheader.110702"
  file_mm = "/home/CMAQ-5.2/data/SE52BENCH/single_day/cctm_input/met/wrf/wrfout_d01_2019-03-17_00_00_00",
  makegrid = .T.
&END

&USERDEFS
  lpv       =  1
  lwout    =  0
  luvcout =  1
  lsat    =  0
  mcip_start = "2019-03-17-00:00:00.0000"
  mcip_end = "2019-03-17-18:00:00.0000"
  intvl    =  180
  coordnam = "LamCon_40N_97W"
  grdnam    = "SE52BENCH"
  ctmlays =  -1.0
  btrim    =  0
  lprt_col =  0
  lprt_row =  0
  wrf_lc_ref_lat = 39.25
&END

&WINDOWDEFS
  x0       =  6
  y0       =  6
  ncolsin =  72
  nrowsin =  100
&END

chenjiao997 · 发表于 2021-12-3 19:17:04

&share
wrf_core = 'ARW',
max_dom = 1,
start_date = '2019-03-17_00:00:00',
end_date = '2019-03-17_18:00:00',
interval_seconds = 21600,
io_form_geogrid = 2,
opt_output_from_geogrid_path = '/home/shangyongpeng/data/domain/shiyan/',
debug_level = 0,
/

&geogrid
parent_id       = 1,
parent_grid_ratio = 1,
i_parent_start = 1,
j_parent_start = 1,
e_we       = 66,
e_sn       = 59,
geog_data_res = '5m',
dx = 11300,
dy = 11300,
map_proj =  'lambert',
ref_lat = 39.25,
ref_lon = 117.926,
truelat1  = 39.25,
truelat2  = 39.25,
stand_lon = 117.926,
geog_data_path = '/home/shangyongpeng/data/geog',
opt_geogrid_tbl_path = '/home/shangyongpeng/data/domain/shiyan/',
ref_x = 33.0,
ref_y = 29.5,
/

&ungrib
out_format = 'WPS',
prefix = 'FILE',
/

&metgrid
fg_name = 'FILE',
io_form_metgrid = 2,
opt_output_from_metgrid_path = '/home/shangyongpeng/data/domain/shiyan/',
opt_metgrid_tbl_path = '/home/shangyongpeng/data/domain/shiyan/',
/

&mod_levs
press_pa = 201300 , 200100 , 100000 ,
         95000 ,  90000 ,
         85000 ,  80000 ,
         75000 ,  70000 ,
         65000 ,  60000 ,
         55000 ,  50000 ,
         45000 ,  40000 ,
         35000 ,  30000 ,
         25000 ,  20000 ,
         15000 ,  10000 ,
            5000 , 1000
/

&domain_wizard
grib_data_path = '/home/shangyongpeng/data/qingzhuanduoyun',
grib_vtable = 'Vtable.GFS',
dwiz_name =shiyan
dwiz_desc =
dwiz_user_rect_x1 =3279
dwiz_user_rect_y1 =499
dwiz_user_rect_x2 =3426
dwiz_user_rect_y2 =643
dwiz_show_political =true
dwiz_center_over_gmt =true
dwiz_latlon_space_in_deg =10
dwiz_latlon_linecolor =-8355712
dwiz_map_scale_pct =25.0
dwiz_map_vert_scrollbar_pos =0
dwiz_map_horiz_scrollbar_pos =0
dwiz_gridpt_dist_km =11.3
dwiz_mpi_command =
dwiz_tcvitals =null
dwiz_bigmap =Y
/

		自动登录	找回密码
密码			立即注册
